Coin Grid-lock Outdoor Deck Flooring

Coin Tiles 2017-08-31T19:44:09+00:00

Color Options:

Specifications:

  • Tile size: from 6 ft to 20ft

  • Material: Polypropylene copolymer

  • UV Stabilized

  • Over 70,000 lbs. rollover capacity

  • Excellent resistance to oil, gas and other automotive fluids

  • Excellent resistance to Alkalis

  • Good resistance to acids and solvents

  • Non-slip

  • Temperature Tolerances: -22°F to +248°F

  • Compressive Strength: 5120 psi

  • UV Stable
  • Fire Rating: HB (Horizontal Burn)

Technical Data:

  • Dimensional Stability: < 0.1 %
  • Indentation: < 0.5 mm
  • Inflammability: Will not support combustion
  • Reflex after ageing: No cracks
  • Resistance to curling: < 0.1 mm
  • Loss in mass after heating: < 0.2 %
  • Static co-efficient of friction: Meets or exceeds 0,6
  • Tile size: 330 x 330 mm
  • Tile thickness: Stud: 6,3 mm, Checkerplate: 7.5 mm
  • Tile mass: Stud: ± 9 kg / m2, Checkerplate: ± 9 kg / m2
  • Hardness: No cracks 88 – 92 Shore A

Textures:
